ALPHA 630, marshaling box, IP55, degree of protection 1, H: 350 mm, W: 550 mm, D: ...
676.64€
Включая НДС
Артикул: 8GK1383-0KK24
ALPHA 630 КРОССИРОВОЧНАЯ КОРОБКА В=350 Ш=550 Г=320 1КЛАСС IP55
Параметры
| Mounting method | Other |
| Protection class | I |
| Colour | Grey |
| Width | 550.0 |
| Height | 350.0 |
| Depth | 320.0 |
| RAL-number | 7035 |
| With mounting plate | Нет |
| Surface protection | Powder coating |
| Built-in depth | 320.0 |
| Number of rows | - |
| Type of cover | Cover |
| Number of conduit inlets | - |
| Extension possible | Да |
| Internal depth | 320.0 |
| Material housing | Steel |
| Circuit integrity | None |
| Width in number of modular spacings | - |
| Suitable for outdoor use | Нет |
| Impact strength | IK09 |
| Number of modules | - |
| Type of door | None |
| Degree of protection (IP) | IP55 |
| Transparent cover/door | Нет |
| With lock | Да |
| Suitable for lightning protection | Да |
| Nominal current (In) | 630 |
| Plate thickness cabinet | - |
| Plate thickness door/cover | 0.75 |
| Cover model | None |
| Number of openings for flange plates | 8 |
| Degree of protection (NEMA) | Other |
