POF Trailing Cable 980/1000, with poly-optic fibers, UL, sold by the meter
8.62€
Включая НДС
Артикул: 6XV1874-2B
SIMATIC NET, POF ГИБКИЙ КАБЕЛЬ 980/1000, PROFINET, ПРОДАЖА ПО МЕТРАЖУ. МАКСИМАЛЬНАЯ ДЛИНА 500 M, МИНИМАЛЬНАЯ ДЛИНА 20 М
Параметры
| UV resistant | - |
| Fibre type | Multi mode 980/1000 |
| Flame retardant | In accordance with EN 60332-1-2 |
| Number of fibres | 2 |
| With strain relief | Да |
| Armouring | Нет |
| Resistant to chemicals | - |
| Circuit integrity | - |
| Colour outer sheath | Green |
| Category | OP1 |
| Material outer sheath | Polyurethane (PUR) |
| Type of tube | Other |
| Number of fibres per tube | 1 |
| Cable metal free | Да |
| Underground installation | Нет |
| Blow in | Нет |
| Outer diameter approx. | 8.0 |
| With rodent protection | Нет |
| Low smoke (acc. EN 61034-2) | Нет |
| Halogen free (acc. EN 60754-1/2) | - |
| Oil resistant (acc. EN 60811-404) | - |
| Longitudinal water blocking cable | Нет |
| Radial water blocking cable | Нет |
| Reaction-to-fire class according to EN 13501-6 | Eca |
| Smoke development class according to EN 13501-6 | - |
| Euro class flaming droplets/particles according to EN 13501-6 | - |
| Euro class acidity according to EN 13501-6 | - |
| Min. permitted bending radius, stationary application/permanent installation | 55.0 |
| Specification material outer sheath | Other |
