SIMATIC S7 S7-GRAPH V5.6 Upgrade
400.98€
Включая НДС
Артикул: 6ES7811-0CC07-0YE5
SIMATIC S7, обновление опционального пакета S7-Graph V5.6, плавающая лицензия на 1 пользователя, ПО разработки, ПО и документация на CD, лицензионный ключ на USB-накопителе, класс A, 5 языков (немецкий, английский, французский, итальянский, испанский), для STEP7 5.6, работа под ОС Windows Server 2008 R2 SP1, Windows Server 2012 R2, Windows Serve SIMATIC S7-GRAPH is based on the STEP 7 programming software. It is used for sequential processes with alternative or parallel step sequences. The sequences are configured and programmed clearly and quickly in a standardized method of representation (according to IEC 61131-3, EN 61131). The process is graphically described and is broken down into individual steps with a manageable functional scope. Actions for the steps can be defined and their execution can be controlled. Transitions (transitional conditions) control the transitions from one step to the next. Interlock and monitoring conditions are defined for each step. S7-Graph is already included in STEP 7 Professional (TIA Portal).
Параметры
| Suitable for safety functions | Нет |
| With editor for programming language IL (Instruction List) | Нет |
| With editor for programming language LD (Ladder Diagram) | Нет |
| With editor for programming language FBD (Function Block Diagram) | Нет |
| With editor for programming language ST (structured text) | Нет |
| With editor for programming language SFC (Sequential Function Chart) | Нет |
| With editor for manufacturer specific programming language | Да |
| Suitable for operating system Windows 9x | Нет |
| Suitable for operating system Windows NT | Нет |
| Suitable for operating system Windows 2000 | Нет |
| Suitable for operating system Windows XP | Да |
| Suitable for operating system Windows ME | Нет |
| Suitable for operating system Windows CE | Нет |
| Suitable for operating system Linux | Нет |
| Suitable for other operating system | Нет |
| Object library | - |
| Integrated diagnosis function | Да |
| Integrated configuration function | Да |
| Integrated evaluation function | Да |
| Integrated application configuration function | Да |
| Integrated data detection function | Да |
| Integrated communication function | Да |
| Technology function integrated | Нет |
| Put into operation function integrated | Нет |
| Simulation function integrated | Нет |
| Integrated motion function | Нет |
| Integrated analysis function | Да |
| Integrated position function | Нет |
| In accordance with IEC 1131-3 (DIN EN 61131-3) | Да |
| Maintenance function integrated | Нет |
| With editor for programming language Flowchart | Нет |
| Suitable for operating system Windows 2003 Server | Нет |
| Suitable for operating system Windows Vista | Нет |
| Suitable for operating system Windows 7 | Да |
| SIL according to IEC 61508 | None |
| Suitable for operating system Windows 8 | Нет |
