SIMATIC S7-400 UR2-H With 2x9 slots, sheet steel For configuring S7-400 central units and expansion units
1 260.55€
Включая НДС
Артикул: 6ES7400-2JA00-0AA0
SIMATIC S7-400H, UR2-H, УНИВЕРС. МОНТ. СТОЙКА ДЛЯ БАЗОВЫХ БЛОКОВ ИЛИ СТОЕК РАСШИРЕНИЯ РЕЗЕРВИРОВАННЫХ СИСТЕМ АВТОМАТИЗАЦИИ S7-400H/FH: 2 СЕКЦИИ ШИН, ДО 9 МОДУЛЕЙ НА СЕКЦИЮ, ПОДДЕРЖКА ФУНКЦИЙ РЕЗЕРВИРОВАННОГО ПИТАНИЯ С ПРИМЕНЕНИЕМ 2 БЛОКОВ ПИТАНИЯ НА КАЖДО
Параметры
| Width | 482.5 |
| Height | 290.0 |
| Depth | 27.5 |
| Suitable for safety functions | Нет |
| Type of voltage (input voltage) | - |
| Number of slots | 18 |
| Redundancy | Да |
| With integrated power supply | Нет |
| Rail mounting possible | Нет |
| Explosion safety category for gas | ATEX gas-ex-protection, Cat. 3G |
| Explosion safety category for dust | - |
| Appendant operation agent (Ex ia) | Нет |
| Appendant operation agent (Ex ib) | Нет |
| Category according to EN 954-1 | - |
| Output voltage at AC 50 Hz | - |
| Output voltage at AC 60 Hz | - |
| Output voltage at DC | - |
| Front build in possible | Да |
| Rack-assembly possible | Да |
| Wall mounting/direct mounting | Да |
| Input voltage at AC 50 Hz | - |
| Input voltage at AC 60 Hz | - |
| Input voltage at DC | - |
| Max. output current AC 50 Hz | - |
| Max. output current AC 60 Hz | - |
| Max. output current DC | - |
| Max. input current AC 50 Hz | - |
| Max. input current AC 60 Hz | - |
| Max. input current DC | - |
| Performance level acc. EN ISO 13849-1 | - |
| Type of output voltage | - |
| SIL according to IEC 61508 | - |
