SIMATIC S7-1200 SB 1223, DI 2x5 V DC/DQ 2x5 V DC 200 kHz
77.50€
Включая НДС
Артикул: 6ES7223-3AD30-0XB0
SIMATIC S7-1200, СИГНАЛЬНАЯ ПЛАТА ДИСКРЕТНОГО ВВОДА/ВЫВОДА SB 1223, 2DI/DQ, =5В 200КГЦ SIMATIC S7-1200 Basic Controller - Flexible thanks to wide variety of communication options If you only have to extend your SIMATIC S7-1200 CPU with a few inputs or outputs, signal boards are a good alternative to signal modules. Signal boards are plugged directly onto the front of the controller (also possible with the CPU 1211C) and are available as digital and analog input, output and hybrid modules. A communications board with an RS 485 interface is also available. Signal boards thus permit subsequent expansion of the configuration without requiring any further space in the control cabinet.
Параметры
| Width | 38.0 |
| Height | 62.0 |
| Depth | 21.0 |
| Input current at signal 1 | - |
| Suitable for safety functions | Нет |
| Number of digital inputs | 2 |
| Number of digital outputs | 2 |
| Time delay at signal exchange | - |
| Voltage type of supply voltage | DC |
| Type of voltage (input voltage) | DC |
| Redundancy | Нет |
| Output current | 0.1 |
| Short-circuit protection, outputs available | Нет |
| Type of digital output | Transistor |
| Type of electric connection | - |
| Explosion safety category for gas | ATEX gas-ex-protection, Cat. 3G |
| Explosion safety category for dust | None |
| Appendant operation agent (Ex ia) | Нет |
| Appendant operation agent (Ex ib) | Нет |
| Category according to EN 954-1 | - |
| Performance level acc. EN ISO 13849-1 | - |
| Supply voltage AC 50 Hz | - |
| Supply voltage AC 60 Hz | - |
| Supply voltage DC | - |
| Permitted voltage at output | - |
| Permitted voltage at input | 0.0 |
| Type of output voltage | DC |
| Digital inputs configurable | Да |
| Digital outputs configurable | Да |
| SIL according to IEC 61508 | - |
