SIMATIC ET 200iSP TM-IM/EM60S Screw terminals
160.34€
Включая НДС
Артикул: 6ES7193-7AA00-0AA0
SIMATIC DP, ET 200ISP, ТЕРМИНАЛЬНЫЙ МОДУЛЬ TM-IM/EM60S ДЛЯ УСТАНОВКИ ИНТЕРФЕЙСНОГО МОДУЛЯ IM152-1 И ОДНОГО ЭЛЕКТРОННОГО МОДУЛЯ, КОНТАКТЫ С ВИНТОВЫМИ ЗАЖИМАМИ
Параметры
| Width | 60.0 |
| Height | 190.0 |
| Depth | 52.0 |
| Suitable for safety functions | Да |
| Type of voltage (input voltage) | DC |
| Number of slots | 2 |
| With pluggable modules, digital I/O | Да |
| With pluggable modules, analogue I/O | Да |
| With pluggable modules, communication modules | Нет |
| With pluggable modules, function and technology modules | Нет |
| With pluggable modules, central modules | Да |
| With pluggable modules, others | Да |
| With integrated power supply | Нет |
| Rail mounting possible | Да |
| Explosion safety category for gas | ATEX gas-ex-protection, Cat. 2G |
| Explosion safety category for dust | ATEX dust-ex-protection, Cat. 2D |
| System accessory | Да |
| Appendant operation agent (Ex ia) | Да |
| Appendant operation agent (Ex ib) | Да |
| Category according to EN 954-1 | - |
| Output voltage at AC 50 Hz | - |
| Output voltage at AC 60 Hz | - |
| Output voltage at DC | 20.4 |
| Front build in possible | Да |
| Rack-assembly possible | Нет |
| Wall mounting/direct mounting | Нет |
| Input voltage at AC 50 Hz | - |
| Input voltage at AC 60 Hz | - |
| Input voltage at DC | 20.4 |
| Max. output current AC 50 Hz | - |
| Max. output current AC 60 Hz | - |
| Max. output current DC | 4.0 |
| Max. input current AC 50 Hz | - |
| Max. input current AC 60 Hz | - |
| Max. input current DC | 4.0 |
| Performance level acc. EN ISO 13849-1 | - |
| Type of output voltage | DC |
| SIL according to IEC 61508 | - |
