Power supply SITOP PSU8200, 3-phase 24 V DC/30-40 A for battery charging
457.92€
Включая НДС
Артикул: 6EP3437-8UB00-0AY0
SITOP PSU3800 24V/30-40A, стабилизированный блок питания, вход: 3х-фазный ~400-500 В, выход: =24 В/30-40 А, оптимизирован для зарядки батарей The SITOP PSU300B 3-phase power supply is optimally suited for battery charging thanks to the constant current characteristic. For other applications, the output characteristic can also be switched to latching disconnection. The 3-phase wide-range input enables worldwide use. The slim design takes up little space on the mounting rail. Installation clearances are not required. Regardless of the industry or requirements, Siemens offers reliable and efficient power supplies for every plant.
Параметры
| Width | 135.0 |
| Height | 145.0 |
| Depth | 150.0 |
| Built-in height | 225.0 |
| Power consumption | - |
| Built-in width | 135.0 |
| Modular version | Да |
| Suitable for safety functions | - |
| Width in number of modular spacings | - |
| Voltage type of supply voltage | AC |
| Power output | 960.0 |
| Output voltage stabilized | Да |
| Type of electric connection | Screw connection |
| Rail mounting possible | Да |
| Wall mounting possible | Нет |
| Stabilized | Да |
| Degree of protection (IP) | IP20 |
| Direct mounting possible | Нет |
| 1st secondary output voltage | 24 |
| 2nd secondary output voltage | - |
| 3rd secondary output voltage | - |
| Secondary voltage adjustable | Да |
| Rated supply voltage at AC 50 Hz | 400 |
| Rated supply voltage at AC 60 Hz | 500 |
| Rated supply voltage at DC | - |
| Short-circuit-proof | Да |
| Performance level acc. EN ISO 13849-1 | - |
| Max. output current 1 | 40 |
| Max. output current 2 | - |
| Max. output current 3 | - |
| Nominal value output voltage 1 | - |
| Nominal value output voltage 2 | - |
| Nominal value output voltage 3 | - |
| Nominal value output current 1 | 40.0 |
| Nominal value output current 2 | - |
| Nominal value output current 3 | - |
| SIL according to IEC 61508 | - |
| Degree of protection (NEMA) | - |
