SIMATIC IPC377E 19" Touch , базовый панельный ПК Celeron N3160 (4C/4T) 4 ГБ RAM 500 ГБ HDD 1 видеовыход DispleyPort 1 видеовыход VGA 2 порта Eth
2 521.10€
Включая НДС
Артикул: 6AV7230-0EA20-1BA0
SIMATIC IPC377E 19" Touch , базовый панельный ПК Celeron N3160 (4C/4T) 4 ГБ RAM 500 ГБ HDD 1 видеовыход DispleyPort 1 видеовыход VGA 2 порта Ethernet RJ45 10/100/1000 Мбит/c 2x USB3.0, 4x USB2.0 6x COM-портов 1x mPCIe-слот 1x mSATA-слот операционная система Windows 7 Ultimate SP1 64-битная =24 В The SIMATIC IPC377E Panel PC combines the openness and performance of an industrial PC with a long-lasting, robust single-touch display with a glass front in display sizes 12", 15" or 19". Flexible installation options (installation in the control cabinet, VESA) vertical and horizontal, industry-standard display for effortless working, fanless device design and appealing packages with HMI software. Horizontal or vertical installation in the control cabinet.
Параметры
| Built-in depth | - |
| Suitable for safety functions | Нет |
| With hard disc | Да |
| With CD-RW drive | Нет |
| Screen diagonal | - |
| Operation temperature | 0 |
| Voltage type of supply voltage | DC |
| Supporting protocol for LON | Нет |
| Number of HW-interfaces industrial Ethernet | 2 |
| Number of HW-interfaces RS-232 | 4 |
| Number of HW-interfaces RS-422 | 2 |
| Number of HW-interfaces RS-485 | 2 |
| Number of HW-interfaces serial TTY | 0 |
| Number of HW-interfaces USB | 4 |
| Number of HW-interfaces parallel | 0 |
| Number of HW-interfaces other | 1 |
| Supporting protocol for ASI | Нет |
| Supporting protocol for PROFIBUS | Нет |
| Supporting protocol for CAN | Нет |
| Supporting protocol for INTERBUS | Нет |
| Supporting protocol for KNX | Нет |
| Supporting protocol for MODBUS | Нет |
| Supporting protocol for Data-Highway | Нет |
| Supporting protocol for DeviceNet | Нет |
| Supporting protocol for SUCONET | Нет |
| Supporting protocol for other bus systems | Нет |
| Number of pixels, horizontal | - |
| Number of pixels, vertical | - |
| With touch screen | - |
| Degree of protection (IP), front side | IP65 |
| Max. main memory | 8000.0 |
| With CD-ROM drive | - |
| With DVD-drive | Нет |
| With DVD RW drive | - |
| With floppy disc drive | Нет |
| With other storage media | Нет |
| Customer individual configuration | Нет |
| Number of free AGP-slots | 0 |
| Number of free PCI-slots | 0 |
| Number of free ISA-slots | 0 |
| Number of free PCMCIA-slots | 0 |
| Number of HW-interfaces SCSI | 0 |
| Number of HW-interfaces PS2 | 0 |
| Integrated keyboard | - |
| Number of function buttons | - |
| Mouse-cursor control integrated | - |
| Width of the front | - |
| Height of the front | - |
| Rail mounting possible | Нет |
| Supporting protocol for SERCOS | Нет |
| Supporting protocol for INTERBUS-Safety | Нет |
| Number of interfaces PROFINET | - |
| Number of HW-interfaces Wireless | - |
| Front build in possible | Да |
| Mounting type, gallows mounting | - |
| Rack-assembly possible | Нет |
| Mounting type, table foot | - |
| Wall mounting/direct mounting | Да |
| Radio standard Bluetooth | - |
| Radio standard WLAN 802.11 | - |
| IO link master | Нет |
| Supporting protocol for AS-Interface Safety at Work | Нет |
| Supporting protocol for DeviceNet Safety | Нет |
| Supporting protocol for EtherNet/IP | Нет |
| Supporting protocol for Foundation Fieldbus | Нет |
| Supporting protocol for PROFINET CBA | Нет |
| Supporting protocol for PROFINET IO | Нет |
| Supporting protocol for PROFIsafe | Нет |
| Supporting protocol for SafetyBUS p | Нет |
| Supply voltage AC 50 Hz | - |
| Supply voltage AC 60 Hz | - |
| Supply voltage DC | 20.4 |
| Preinstalled operating system | Windows 7 |
| Type of display | - |
| Radio standard GPRS | Нет |
| Radio standard GSM | Нет |
| Radio standard UMTS | Нет |
| Number of buttons with LED | - |
| Number of system buttons | - |
| Degree of protection (NEMA) | - |
