SIPLUS S7-300 SM 322, DQ 8x relay 24 V DC/230 V AC/5 A With conformal coating based on 6ES7322-5HF00-0AB0

SIPLUS S7-300 SM 322, DQ 8x relay 24 V DC/230 V AC/5 A With conformal coating based on 6ES7322-5HF00-0AB0. 6AG13225HF004AB0
488.45€
Включая НДС
Артикул: 6AG1322-5HF00-4AB0
SIPLUS S7-300 МОДУЛЬ РЕЛЕЙНОГО ВЫВОДА SM322 8RO, ДЛЯ ТЯЖЁЛЫХ УСЛОВИЙ ПРИМЕНЕНИЯ, НА ОСНОВЕ МОДУЛЯ 6ES7322-5HF00-0AB0 Just like the CPU, the digital output modules are also protected against extreme ambient conditions. Due to the 100% conformal coating they can withstand biologically, chemically and physically active substances, condensation, frost, and corrosive gases. Regardless of the conditions, your digital signals are reliably output.

Параметры

Width 40.0
Height 125.0
Depth 120.0
Input current at signal 1 -
Suitable for safety functions Нет
Number of digital inputs 0
Number of digital outputs 8
Time delay at signal exchange -
Voltage type of supply voltage DC
Type of voltage (input voltage) -
Redundancy Нет
Output current 5.0
Short-circuit protection, outputs available Нет
Type of digital output Relay
Type of electric connection Screw-/spring clamp connection
Explosion safety category for gas ATEX gas-ex-protection, Cat. 3G
Explosion safety category for dust None
Appendant operation agent (Ex ia) Нет
Appendant operation agent (Ex ib) Нет
Category according to EN 954-1 -
Performance level acc. EN ISO 13849-1 -
Supply voltage AC 50 Hz -
Supply voltage AC 60 Hz -
Supply voltage DC 20.4
Permitted voltage at output 0.0
Permitted voltage at input -
Type of output voltage AC/DC
Digital inputs configurable -
Digital outputs configurable Да
SIL according to IEC 61508 -
