SIPLUS S7-300 SM 322, DQ 32x24 V DC/0.5 A -25 ... +70 °C based on 6ES7322-1BL00-0AA0
1 143.53€
Включая НДС
Артикул: 6AG1322-1BL00-2AA0
МОДУЛЬ SIPLUS SM322 ДЛЯ S7-300, ТЕМПЕРАТУРНЫЙ ДИАПАЗОН -25... +60С, 40-ПОЛЮСНЫЙ РАЗЪЕМ, ОСНОВАН НА МОДУЛЕ 6ES7322-1BL00-0AA0 Just like the CPU, the digital output modules are also protected against extreme ambient conditions. Due to the 100% conformal coating they can withstand biologically, chemically and physically active substances, condensation, frost, and corrosive gases. Regardless of the conditions, your digital signals are reliably output.
Параметры
Width | 40.0 |
Height | 125.0 |
Depth | 120.0 |
Input current at signal 1 | - |
Suitable for safety functions | Нет |
Number of digital inputs | 0 |
Number of digital outputs | 32 |
Time delay at signal exchange | 0.1 |
Voltage type of supply voltage | DC |
Type of voltage (input voltage) | - |
Redundancy | Нет |
Output current | 0.5 |
Short-circuit protection, outputs available | Да |
Type of digital output | Transistor |
Type of electric connection | Screw-/spring clamp connection |
Explosion safety category for gas | - |
Explosion safety category for dust | - |
Appendant operation agent (Ex ia) | - |
Appendant operation agent (Ex ib) | - |
Category according to EN 954-1 | - |
Performance level acc. EN ISO 13849-1 | - |
Supply voltage AC 50 Hz | - |
Supply voltage AC 60 Hz | - |
Supply voltage DC | 20.4 |
Permitted voltage at output | 0.0 |
Permitted voltage at input | - |
Type of output voltage | DC |
Digital inputs configurable | - |
Digital outputs configurable | Да |
SIL according to IEC 61508 | - |
