SIPLUS S7-300 SM 321, DI 8x120/230 V AC ISOL -25 ... +70 °C based on 6ES7321-1FF10-0AA0
559.68€
Включая НДС
Артикул: 6AG1321-1FF10-7AA0
SIPLUS S7-300, МОДУЛЬ ДИСКРЕТНОГО ВВОДА SM321 8 DI, РАСШИРЕННЫЙ ДИАПАЗОН РАБОЧИХ ТЕМПЕРАТУР -25... +70 ГРАДУСОВ ЦЕЛЬСИЯ, НА ОСНОВЕ МОДУЛЯ 6ES7321-1FF10-0AA0 Just like the CPU, the digital input modules are also protected against extreme ambient conditions. Due to the 100% conformal coating they can withstand biologically, chemically and physically active substances, condensation, frost, and corrosive gases. Regardless of the conditions, your digital signals are reliably recorded.
Параметры
| Width | 40.0 |
| Height | 125.0 |
| Depth | 120.0 |
| Input current at signal 1 | 7.5 |
| Suitable for safety functions | Нет |
| Number of digital inputs | 8 |
| Number of digital outputs | 0 |
| Time delay at signal exchange | 15.0 |
| Voltage type of supply voltage | AC |
| Type of voltage (input voltage) | AC |
| Redundancy | Да |
| Output current | - |
| Short-circuit protection, outputs available | - |
| Type of digital output | None |
| Type of electric connection | Screw-/spring clamp connection |
| Explosion safety category for gas | ATEX gas-ex-protection, Cat. 3G |
| Explosion safety category for dust | None |
| Appendant operation agent (Ex ia) | Нет |
| Appendant operation agent (Ex ib) | Нет |
| Category according to EN 954-1 | - |
| Performance level acc. EN ISO 13849-1 | - |
| Supply voltage AC 50 Hz | 93 |
| Supply voltage AC 60 Hz | 93 |
| Supply voltage DC | - |
| Permitted voltage at output | - |
| Permitted voltage at input | 0.0 |
| Type of output voltage | - |
| Digital inputs configurable | Да |
| Digital outputs configurable | - |
| SIL according to IEC 61508 | - |
