OFF switch 80 A 4-pole.

ВЫКЛЮЧАТЕЛЬ НАГРУЗКИ 80A 4-ПОЛ. On/off switches for mounting on standard rails for controlling electrical systems. The 5TL1 On/Off switches are used for the switching of lighting, motors and other electrical devices. Rated currents range from 32 A to 125 A. The 5TL1 device versions can also be used as switch disconnectors according to EN 60947-1 and serve as main control switches for the disconnection or isolation of plants according to EN 60204-1. Whether for infrastructure or for industrial requirements, Siemens provides switchgears for all applications and every application area. The new design of the 5TL1 On/Off switches means they are optically perfectly integrated into the RCCB and MCB series. Key features of the switchgears from Siemens: 1. Increased operational safety and system availability due to separate connection and disconnection of the affected circuit. 2. Reliable safety during installation with standard reach-around and touch protection. 3. Toolless removal from the DIN rail or from the bus bar assembly by means of conveniently actuating a manual slide. 4. Clearly visible switch position indicator. 5. Can be used as switch disconnector and main switch. 6. The on/off switches comply with the provisions of EN 60947-1 and EN 60204-1. 7. Optimized technology for your safety – only from Siemens. www.siemens.com/lowvoltage. Siemens offers a comprehensive portfolio of protection, switching, measuring and monitoring devices, distribution systems as well as switches and sockets for safe and efficient electrical infrastructure in buildings and industry.

Параметры

Voltage type	AC
Switching function	Other
With signal lamp	Нет
Built-in depth	70.0
Rated current	80.0
Rated voltage	440
Max. lamp power	-
Number of poles	4
Lamp type	Other
Short-circuit breaking capacity (Icw)	10.0
Rated switching capacity	0.24
Width in number of modular spacings	4
Colour calotte	Other
Lamp socket	Other
Min. rated voltage	-
Forced segregation (according to DIN VDE 0113)	Нет
Degree of protection (IP)	Other
Number of contacts as normally closed contact	-
Number of contacts as normally open contact	4
Number of contacts as change-over contact	-
