RCBO, 10 kA, 1P+N, type AC, 30 mA, C-char, In: 25 A, Un AC: 230 V

ДИФФ.АВТОМАТ ТИП AC , УСТ. ГЛУБИНА=70 MM IFN 30MA, 10KA, 1+N-ПОЛ. ТИП C 25A RCBOs for combined short-circuit protection and anti-contact protection. An important element of the SENTRON protective devices for electrical installations, the patented RCBOs from Siemens allow combined personnel, fire and cable protection in just one device. In addition to detecting the fault currents, they also provide reliable protection against short-circuits and overloads thanks to the integrated overcurrent protective device. As a combination of residual current and miniature circuit breaker, the Siemens RCBOs are primarily characterized by: 1. Increased operational safety and system availability due to separate disconnection of the affected circuit. 2. Whether sinusoidal residual alternating currents or smooth residual direct currents, Siemens provides the right type for all requirements and special versions. 3. Reliable safety during installation due to standard reach-around and touch protection. 4. Toolless removal from the standard mounting rail or from the busbar assembly simply by operating a manual slide. 5. Clearly visible switch position indicator. 6. The data matrix code on the front of the device provides quick and easy access to information on all aspects of the RCBOs. 7. Be protected according to the standards: The RCBOs correspond to the provisions of DIN VDE. 8. Optimized technology for your safety - only from Siemens. https://www.siemens.com/global/en/home/products/energy/low-voltage/components/sentron-protection-devices/residual-current-protective-devices.html. Siemens offers a comprehensive portfolio of protection, switching, measuring and monitoring devices, distribution systems as well as switches and sockets for safe and efficient electrical infrastructure in buildings and industry.

Параметры

Voltage type	AC
Built-in depth	70.0
Rated current	25
Rated voltage	230
Release characteristic	C
Rated insulation voltage Ui	264
Rated fault current	0.03
Leakage current type	AC
Surge current capacity	1.0
Current limiting class	3
Over voltage category	3
Pollution degree	2
Width in number of modular spacings	2
Frequency	50
Degree of protection (IP)	IP20
Number of protected poles	1
Concurrently switching N-neutral	Да
Rated short-circuit breaking capacity IEC 60947-2	20.0
Suitable for flush-mounted installation	Да
Connectable conductor cross section solid-core	0.75
Connectable conductor cross section multi-wired	0.75
With interlocking device	Да
Ambient temperature during operating	-
Number of poles (total)	2
Anti-nuisance tripping version	Да
Rated impulse withstand voltage Uimp	4.0
Rated short-circuit breaking capacity Icn acc. EN 61009-1	10.0
Disconnection characteristic	Undelayed
Rated short-circuit breaking capacity acc. EN 61009	10.0
