Indicator light, 22 mm, round, metal front ring, green, LED module, 24 V AC/DC

Индикаторная лампа, в форме нажимной кнопки с сигнализацией, 22 мм, кругл., пластмасса с металлическим фронтальным кольцом, цвет: зеленый, с держателем, светодиодный модуль, со встроенным светодиодом, 24 В AC/DC пружинная клемма Indicator lights SIRIUS ACT for signaling switching states or faults in systems with high luminosity, thanks to energy-efficient LED technology. Under the brand name SIRIUS ACT, Siemens offers a unique portfolio of pushbuttons and signaling devices with global product approvals in four modern design lines of rugged genuine metal and high-grade plastic. An innovative snap-on concept makes the task of installing a unit so easy that it can be done with one hand and without any special tools. Groove-free holes are adequate as mounting holes since full twist prevention is already integrated. Thanks to the high degree of protection throughout, the rugged devices are suitable for use in industry and outdoors. Even cleaning with a high-pressure jet is possible. Neither dust, oils, nor caustic solutions can interfere with reliable operation. As well as standard wiring, the devices can also be connected to the controller via PROFINET, AS-Interface or IO-Link. Doing so will help you to reduce wiring time and effort, minimize error sources and have more flexibility. The graphical Online Configurator provides convenient support when selecting and ordering individual devices, enclosures and labels. Extensive documentation (e.g. manual, 3D data, terminal diagram) is available. Versions available: Several colors, various voltage variants. Note: Complete unit, delivery includes holders and modules. SIRIUS ACT - Performance in action for control and signalling. Simply mounted, simply strong, simply perfect.

Параметры

Hole diameter	22.3
Colour button	Green
Suitable for illumination	Да
Number of command positions	1
Spring-return	Нет
Type of button	Flat
Colour front ring	Grey
Type of electric connection	-
Width opening	29.5
Height opening	11.0
Degree of protection (IP)	IP67/IP69K
Material front ring	Metal
With front ring	Да
Construction type lens	-
Supply voltage lamp	24
Switching function latching	Нет
Number of contacts as normally closed contact	-
Number of contacts as normally open contact	-
Number of contacts as change-over contact	-
Degree of protection (NEMA)	1, 2, 3, 3R, 4, 4X, 12, 13
