SIRIUS POSITION SWITCH METAL ENCLOSURE В СООТВ. С EN50047, 31MM DEVICE CONNECTION 1X (M20X1.5), 1NO/2NC КОНТАКТЫ ПЛАВНОГО ХОДА (SLOW-ACTION)S, ROUNDED

SIRIUS POSITION SWITCH METAL ENCLOSURE В СООТВ. С EN50047, 31MM DEVICE CONNECTION 1X (M20X1.5), 1NO/2NC КОНТАКТЫ ПЛАВНОГО ХОДА (SLOW-ACTION)S, ROUNDED ПЛУНЖЕР,FORM B, FUNCTIONAL AT -40 DEGREES, SHOCK-AND VIBRATION TEST ACC. TO EN61373, CATEGORY 1B Mechanical position switches SIRIUS 3SE5 for position sensing of machine parts and position monitoring of protection equipment for extreme environmental conditions down to -40 °C, e.g. in wind energy plants, in the food and beverage industry, or for railway applications. Due to their high degree of protection, the devices are suitable for use in extreme environmental conditions. They have increased corrosion protection, have been tested for shock and impact, and are approved worldwide (IEC, UL). With the corresponding switch configuration, the highest safety requirements specified by PL e or SIL 3 can be met. Various enclosure sizes are available in plastic or metal. In addition, versions are available with separate actuator or tumbler. Depending on the design, various operating mechanisms and separate actuators are available. Safety is a SIRIUS business.

Параметры

Switching function	Slow-action switch
Rated operation current Ie at AC-15, 230 V	-
Rated operation current Ie at DC-13, 230 V	-
Material housing	Metal
Suitable for safety functions	Да
Coating housing	Lacquered
With status indication	Нет
Type of interface for safety communication	None
Type of electric connection	Cable entry metrical
Explosion safety category for gas	None
Explosion safety category for dust	None
Construction type housing	Cuboid
Degree of protection (IP)	IP66/IP67
Forced opening	Да
Number of safety auxiliary contacts	2
Type of control element	Plunger
Type of interface	None
Output electronic	Нет
Rated operation current Ie at AC-15, 125 V	-
Rated operation current Ie at AC-15, 24 V	6
Rated operation current Ie at DC-13, 125 V	0.55
Rated operation current Ie at DC-13, 24 V	3
Width sensor	31.0
Diameter sensor	-
Height of sensor	33.0
Length of sensor	75.7
Switching function latching	Нет
Ambient temperature during operating	-40
Number of contacts as normally closed contact	2
Number of contacts as normally open contact	1
Number of contacts as change-over contact	0
Alignment of the control element	Roller cam straight
Degree of protection (NEMA)	-
