Hinge switch, with aluminum hinge 1 NO/2 NC slow-action contacts
142.00€
Включая НДС
Артикул: 3SE2283-0GA53
Шарнирный выключатель Корпус из пласт. с алюминиевым шарниром контакты зависимого действия 1 НО/2 НЗ для профилей 40 мм угол переключения 8° Поставка с дополнительным шарниром и крепежным материалом Safety hinge switches SIRIUS 3SE228 for tamper-proof monitoring of hinged doors and flaps.
Maximum tamper protection based on the keyed connection between the switch and protective door hinge directly at the pivot point of the protective device. Small actuating angle of 10°.
Safety is a SIRIUS business.
Параметры
| Rated operation current Ie at AC-15, 230 V | 2 |
| Rated operation current Ie at DC-13, 230 V | - |
| Material housing | Plastic |
| Suitable for safety functions | Да |
| Coating housing | Other |
| With status indication | Нет |
| Type of switching contact | Slow-action switch |
| Type of interface for safety communication | None |
| Type of electric connection | Cable entry metrical |
| Explosion safety category for gas | None |
| Explosion safety category for dust | None |
| Construction type housing | Special construction |
| Degree of protection (IP) | IP65 |
| Forced opening | Да |
| Number of safety auxiliary contacts | 2 |
| Type of control element | Other |
| Type of interface | None |
| Rated operation current Ie at AC-15, 125 V | 4.2 |
| Rated operation current Ie at AC-15, 24 V | - |
| Rated operation current Ie at DC-13, 125 V | - |
| Rated operation current Ie at DC-13, 24 V | 1 |
| Width sensor | 111.5 |
| Height of sensor | 36.0 |
| Length of sensor | 92.0 |
| Number of contacts as normally closed contact | 2 |
| Number of contacts as normally open contact | 1 |
| Number of contacts as change-over contact | 0 |
| Degree of protection (NEMA) | - |
