Toggle switch, 16 mm, round plastic, green

КОМПЛЕКТНОЕ УСТРОЙСТВО ДИАМ. 16MM ПЕРЕКЛЮЧАТЕЛЬ 0-I, С ФИКСАЦИЕЙ ЗЕЛЕНАЯ, 1НO Selector switches SIRIUS 3SB2 for switching and controlling electrical loads. The industry-standard 3SB2 pushbuttons and indicator lights have a modular design and are proven in practice. Thanks to their compact design, they are particularly suitable for small control panels. They are extremely functional and rugged, and comply with the IEC/EN 60947-5-1 and 60947-5-5 standards. They can be installed with a high packing density and without the need for any special tools. Versions available: Several colors, 2-3 switching positions, latching/momentary contact operation. Note: Complete unit, supplied with holder and contact block(s). 3SB2 - Space-saving, proven in practice and industry standard!

Параметры

Hole diameter	16.0
Colour button	Green
Number of switch positions	2
Suitable for illumination	Нет
Spring-return	Нет
Colour front ring	Black
Type of electric connection	Flat plug-in connection
Supply voltage	5
Width opening	19.0
Height opening	17.0
Degree of protection (IP)	IP65
With light source	-
Material front ring	Plastic
With front ring	Да
Type of control element	Toggle
Switching function latching	Нет
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	1
Number of contacts as change-over contact	0
Degree of protection (NEMA)	-
