Contactor, AC-1, 140 A/690 V/40 °C, 3-pole, 230 V AC/50 Hz, 1 NO+1 NC

Контактор, AC-1, 140 А/690 В/40 °C, S3, трехполюсный, 230 В AC/50 Гц, 1 НО + 1 НЗ, рамочная клемма/винтовой зажим Contactor SIRIUS 3RT24 for switching resistive loads (AC-1). 3RT24 contactors are part of the SIRIUS modular system with its optimally coordinated products. They offer convincing performance from a compact design with high contact reliability. They can be combined with a variety of other components in the load feeder. Many of the device combinations have been factory tested. The contactors offer the best connection to the automation level for every application (parallel, via ASi or IO-Link): Integrated auxiliary switches reduce the complexity of your configuration. The front-panel terminals simplify the wiring. 3RT24 contactors are climate-resistant and approved for worldwide use (e.g. IEC and UL/CSA). They are available in various sizes and in a wide performance range with AC and DC operation with screw terminals. The comprehensive range of accessories, such as auxiliary switches, auxiliary releases etc. is standardized for all sizes. Simple, efficient and always up to date - SIRIUS modular system.

Параметры

Modular version	Да
Rated operation power at AC-3, 400 V	-
Number of main contacts as normally open contact	3
Number of normally closed contacts as main contact	-
Number of auxiliary contacts as normally open contact	1
Number of auxiliary contacts as normally closed contact	1
Rated operation current Ie at AC-3, 400 V	44
Rated operation current Ie at AC-1, 400 V	140
Rated control supply voltage Us at AC 50HZ	230
Rated control supply voltage Us at AC 60HZ	-
Rated control supply voltage Us at DC	-
Type of electrical connection of main circuit	Frame clamp
Voltage type for actuating	AC
Rated operation current Ie at AC-4, 400 V	-
Rated operation power at AC-4, 400 V	-
Rated operation power NEMA	-
